Lenovo IdeaCentre Q200 User Manual
Page 24
21
Hardware Replacement Guide
13. Lift the heat sink and fan assembly off the failing system board. Place the
heat sink on its side so that the thermal grease does not come in contact with
anything.
14. To remove the microprocessor from the system board, lift the small handle
and open the retainer .
31032756_HaWaii-HRG_EN.indd 21
2008.1.8 3:31:36 PM
