V ——— Video Connector: To connect with the Video to S-Video converting
cable provided in the computer. (Some models are equipped with
this connector.)
FM ———— FM Antenna Connector: To connect an FM antenna provided with
the computer. (Some models are equipped with this connector.)
———— TV Antenna Connector: To connect the signal input cable for the
CATV. (Some models are equipped with this connector)
L&R ——— Left and right audio connector: Audio input connector. (Some
models are equipped with this connector.)
——— Audio Line-in Connector: To connect audio input to the computer.
— Audio Line-out Connector: To connect to the speakers or
headphones.
———— Microphone Jack: To connect to audio input from a microphone.
Identifying parts on the system board
The system board (sometimes called the planar or motherboard) is the main circuit
board in your computer. It provides basic computer functions and supports a
variety of devices that are factory-installed or that you can install later.
The following illustration shows the locations of parts on the system board (some
models).
