Internal drives
Internal drives are devices that your server uses to read and store data. You can add drives to your server to
increase storage capacity and enable your server to read other types of media. Internal drives are installed in
bays. In this manual, the bays are referred to as bay 1, bay 2, and so on.
Figure 7 “Drive bay locations” on page 16 shows the locations of the drive bays.
Figure 7. Drive bay locations
The following list describes the type and size of the drive that you can install in each bay:
1 Bay 1 - Optical drive bay (with an optical drive installed on some models)
2 Bay 2 - Optical drive bay
3 Bay 3 - Card reader drive bay
4 Bay 4 - Secondary SATA hard disk drive bay
5 Bay 5 - Primary SATA hard disk drive bay (with a 3.5-inch SATA hard disk drive installed)
