Audiovox 128-6927 - Manual (Page 8)

Figure 6 illustrates the controls and indicators of the (RVMPKG3) rear
view mirror
:
A: Rearview mirror
B: 4” LCD panel
C: Brightness Control knob
D: Power indicator (Red when power is on)
E: Volume Control Knob
F: Switch 1 (see below)
G: Switch 2 (see below)
H: Speakers
SW1 and SW2:
SW1: Used to turn the LCD on/off .
SW2: Used to toggle display image between rearview camera and
DVD/VCR.
Specifications
General
Power Supply 12VDC
Power Consumption <10W
Current Draw <500 mA
Video Input 1Vp-p@ 75 Impedance
Audio Input <=500mV
Audio Power Output 0.5W × 2 (16O)
Operating Temperature Range -10? to 60?
Overall Dimension 11W×3.75H×1.25D inch
Display System
Screen 4” TFT Color LCD
Brightness 250 nit
