128-7201
1 of 20
Model APS 686T
Installation Manual
4 Channel Remote Start / Keyless Entry System
Installation Instructions
This Unit Is Intended For Installation In Vehicles With
12 Volt Negative Ground Electrical Systems,
Gasoline or Diesel With True Tach Reference
And Automatic Transmissions Only.
Kit Contents
Control Module
(2) - 4 Button Code Hopping Transmitters
4 Channel Code Learning Receiver
External Superheterodyne Antenna/Receiver
(1) - Multi Pin Input/Output Harness
(1) - Six Pin Power Harness
(1) - Four Pin Auxiliary Harness
(1) - Two Pin I/O Harness
(1) - Accessory 2 Pin Connector
(1) - 2 Pin Door Lock Harness
(2) - 30 Amp In-line Fuse Holders With Fuses
(1) - Control Switch
(1) - Programming Switch
(1) - Ring Terminal
(4) - 1/2" Long Screws
(1) - Pin Switch
(1) - Remote Start Warning Label
(1) - Literature Package
Released: 6-28-04
