47
Lenovo G40-30/G40-45/G40-70/G40-70m/Z40-70/Z40-75
1090 Keyboard bezel
For access, remove these FRUs in order:
• “1010 Battery pack” on page 33
• “1020 Base cover” on page 34
• “1030 Optical drive” on page 36
• “1040 Hard disk drive” on page 37
• “1070 Fan assembly” on page 42
• “1080 Keyboard” on page 44
Figure 9. Removal steps of keyboard bezel
Remove the screws 1.
Step Screw (quantity) Color Torque
1 M2 × 3.5 mm, flat-head, nylok-coated (10)
D to C (type2)
Black 1.5 ~ 2.0 kgf*cm
