Chapter 1. Product overview
This chapter provides an overview of the tablet, including the locations of the connectors and controls, tablet
features, accessories, specifications, and operating environment.
Tablet layout
This topic introduces the tablet hardware features to give you the basic information you will need to start
using the tablet.
Front and side view
Figure 1. ThinkPad Tablet front and side view
1 Power button 12 ThinkPad Tablet Pen storage
2 Headphone or microphone connector 13 ThinkPad Tablet Pen string holes
3 Mini HDMI connector 14 Volume control button
4 Micro USB connector 15 Ambient light sensor
5 ThinkPad Tablet Dock connector 16 Front-facing camera
6 SIM card slot 17 Multitouch screen
7 Emergency reset hole 18 Home button
© Copyright Lenovo 2011, 2012 1
