Note: You can disable all of the four physical buttons ( 18 Home button, 19 Back button, 20 Browser
button, and 21 Screen rotation lock button) by going to the Android Settings screen and touching Display
➙ Disable Physical Buttons.
Back-side view
Figure 2. ThinkPad Tablet back-side view
1 Microphone 3 Rear-facing camera
2 System-status indicator
1 Microphone
The built-in microphone captures sound and voice when it is used with an application capable of handling
audio.
2 System-status indicator
The illuminated dot in the ThinkPad logo on the backside of the tablet works as a system-status indicator.
The system-status indicator is on when the tablet is on and in use. When the tablet is in sleep mode or is
turned off, the indicator is off.
3 Rear-facing camera
Your tablet has a 5-megapixel rear-facing camera, which you can use to take pictures and create videos. For
more information, see “Using the cameras” on page 34.
