Removal steps of touch pad for Lenovo V580 models

Remove the touch pad cable and then push the touch pad in the direction shown by the arrow

3

.

1

2

3

Remove the touch pad in the direction shown by the arrow

4

.

4

64

Hardware Maintenance Manual
