AMPSUB210 SPECIFICATIONS
8 ohm Power: 200W RMS total at 8 ohms,
20Hz - 500Hz, <0.1% THD+N
4 ohm Power: 300W total at 4 ohms,
20Hz- 500Hz, <0.1% THD+N
Frequency Response: 5Hz - 500Hz, +0dB, -3dB
Signal to Noise Ratio: 100dB A-weighted, referred to rated
power at 4 ohms
Sensitivity: Variable, 350mV to 2.8V for rated
power at 8 ohms
AC Power Consumption: 700W maximum
Net Weight: 23.1lbs / 10.5kgs
Gross Weight: 30.8lbs / 14.0kgs
AudioSource®
9200 North Decatur St.
Portland, OR 97203
503.286.9300
www.audiosource.net AMPSUB210 Owner’s Manual 8100.0361A
AMPSUB210
OWNER’S MANUAL
3.8”
(96.5mm)
16.5” (419mm)
13.75”
(349mm)
Power
Signal Clip
AMPSUB210
Subwoofer Power Amplifier
Min Max
Volume
Min Max
Volume
40Hz 500Hz
Variable
5Hz 50Hz
Subsonic
