Asus P5GD2 - Manual (Page 33)

A S U S P 5 G D 2 A S U S P 5 G D 2 A S U S P 5 G D 2 A S U S P 5 G D 2 A S U S P 5 G D 2 2 - 1 1 2 - 1 1 2 - 1 1 2 - 1 1 2 - 1 1
2. Push each of the pins
downward to secure the
heatsink and fan assembly in
place. 3. Rotate the push-pins clockwise
to lock.
4. When the fan and heatsink assembly is in place, connect the CPU fan
cable to the connector on the motherboard labeled CPU_FAN1.
Do not forget to connect the CPU fan connector! Hardware monitoring
errors can occur if you fail to plug this connector.
P5GD2
R
P5GD2 CPU Fan connector
CPU_FAN1
GND CPU F
AN PWR
CPU F
AN IN
CPU F
AN PWM
