Asus P5GD2 User Manual

Page 27

A S U S P 5 G D 2

2 - 5

2.2.5

Layout Contents

S l o t s

P a g e

1. DDR2 DIMM slots

2-13

2. PCI slots

2-18

3. PCI Express slot

2-18

J u m p e r s

P a g e

1. Clear RTC RAM (3-pin CLRTC1)

2-19

2. USB Device wake-up (3-pin USBPW12, USBPW34, USBPW56, USBPW78)

2-20

3. Keyboard power (3-pin KBPWR1)

2-21

R e a r p a n e l c o n n e c t o r s

P a g e

1. Parallel port

2-22

2. RJ-45 port

2-22

3. Rear Speaker Out port (gray)

2-22

4. Side Speaker Out port (black)

2-22

5. Line In port (light blue)

2-22

6. Line Out port (lime)

2-22

7. Microphone port (pink)

2-23

8. Center/Subwoofer port (yellow orange)

2-23

9. USB 2.0 ports 3 and 4

2-23

10. USB 2.0 ports 1 and 2

2-23

11. Optical S/PDIF out port

2-23

12. Coaxial S/PDIF out port

2-23

13. PS/2 keyboard port (purple)

2-23

14. PS/2 mouse port (green)

2-23
