MS-7677
ReaR PaneL
the rear panel provides the following connectors:
HaRdWaRe SetuP
this section provides instructions on CPu and memory installation, as well as
jumper settings on the mainboard. While doing the installation, be careful in hold-
ing the components and follow the installation procedures.
CPu & Cooler installation Procedures for LGa55
When you are installing the CPu, make sure that you install the cooler to prevent
overheating. if you do not have the CPu cooler, consult your dealer before turning
on the computer.
introduction to LGa 55 CPu
the figure below shows the surface of LGa 55 CPu. Remember to apply some
thermal paste on it for better heat dispersion.
iMPoRtant
Please use the boxed CPu fan or other enhanced coolers to maintain the system
stability.
Mouse
keyboard
VGa Port
Lan
uSB Ports
Line-in
Line-out
MiC
note: to reach the 8-channel sound effect, the 7th and 8th channels must be
output from front panel.
alignment key
yellow triangle is the Pin indicator
alignment key
uSB Ports
HdMi Port
