2-15
MS-7758
Chapter 2
GT Rato
Ths settng controls the rato of ntegrated graphcs frequency to enable the ntegrated
graphcs to run at dfferent frequency combnatons.
Adjusted GT Frequency
It shows the adjusted ntegrated graphcs frequency. Read-only.
Spread Spectrum
Ths functon reduces the EMI (Electromagnetc Interference) generated by modulatng
clock generator pulses.
Important
If you do not have any EMI problem, leave the settng at [Dsabled] for optmal system
stablty and performance. But f you are plagued by EMI, select the value of Spread
Spectrum for EMI reducton.
The greater the Spread Spectrum value s, the greater the EMI s reduced, and the
system wll become less stable. For the most sutable Spread Spectrum value, please
consult your local EMI regulaton.
Remember to dsable Spread Spectrum f you are overclockng because even a slght
jtter can ntroduce a temporary boost n clock speed whch may just cause your
overclocked processor to lock up.
CPU Core Voltage/ DRAM Voltage.
These tems are used to adjust the voltages.
Current CPU Core Voltage/ Current DRAM Voltage
These tems show current voltages. Read-only.
OC Retry Count [1]
Ths tem s used to set the number of bootng tmes wth the present over-clockng
settngs. If over-clockng has faled wth the desgnated bootng tmes, the system wll
restore the defaults at next boot.
Overclockng Profiles
Press
Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Press
Set Name for Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Gve a name by typng n ths tem.
Save Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Save the current overclockng settngs to ROM for selected profile.
Load/ Clear Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Load/ Clear the stored profile settngs from ROM.
OC Profile Save to USB
Save the current overclockng settngs to USB flash dsk.
OC Profile Load from USB
Load the stored settngs from USB flash dsk.
▶
▶
▶
•
•
•
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
