2-8
BIOS Setup
Intel(R) Rapd Start Technology
Press to enter the sub-menu.
Intel(R) Rapd Start Technology
Ths tem s used to enable/ dsable the Intel Rapd Start technology.
USB Configuraton
Press to enter the sub-menu.
USB Controller
Ths tem allows you to enable/ dsable the ntegrated USB 2.0 controller.
Legacy USB Support
Enable or dsable support for USB keyboards, mce and floppy drves. You wll be
able to use these devces wth operatng systems that do not support USB.
Super IO Configuraton
Press to enter the sub-menu.
Seral(COM) Port 0 Configuraton
Press to enter the sub-menu.
Seral (COM) Port0
Ths tem allows you to enable/ dsable the seral port.
Seral (COM) Port0 Settngs
Select an address and correspondng nterrupt for the seral port.
Parallel(LPT) Port Configuraton
Press to enter the sub-menu.
Parallel(LPT) Port
Ths tem allows you to enable/ dsable the parallel port.
Parallel(LPT) Port Settngs
Select an address and correspondng nterrupt for the parallel port.
Devce Mode
Select a devce mode for the parallel port.
Hardware Montor
Press to enter the sub-menu.
CPU Smart Fan Target
Controls CPU fan speed automatcally dependng on the current temperature and
to keep t wth a specfic range. If the current CPU temperature reaches the target
value, the smart fan functon wll be actvated.
SYS Fan1/ SYS Fan2 Control
These tems allow users to select how percentage of speed for the SYSFAN1/
SYSFAN2.
CPU/ System Temperature, CPU FAN/ SYS FAN 1/ SYS FAN2 Speed
These tems show the current status of all of the montored hardware devces/
components such as CPU temperature/ system temperature and the few fans’
speeds.
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
