Page 4
4
1-4. Dimensions
Note: Housing Dimensions and Base Configurations vary.
Table 2. Upright Models
Note: Dimensions are subject to change without notice.
Model
A
B
C
F
G
H
I
J
K
N u m b e r
Rating
( i n )
( i n ) ( i n )
( i n )
( i n ) ( i n ) ( i n )
( i n )
( i n )
U M - 2 5 5 6 1/4 Ton Raise + 1 1/2 5 / 8 2 3/8 0 . 3 1 2
7 / 8
3 / 8 2 1/4 4 Holes- 9/32 Dia. on 1 3/4 Dia. B.C.
1
U M - 2 6 2 6 1/2 Ton Raise + 1 7/8 5 / 8 2 3/8 0 . 4 3 7
7 / 8
3 / 8 2 1/4 4 Holes- 9/32 Dia. on 1 3/4 Dia. B.C.
1
U M - 2 5 0 2 1 Ton Raise + 1 3/4 5 / 8 3 1/4 0 . 5 0 0 1 1/2 1 / 2 3 1/4 4 Holes-13/32 Dia. on 2 3/8 Dia. B.C. 1 1/2
