CDB1601-120W
DS931DB4 5
3. BILL OF MATERIALS
&,5586/2*,& &'%:B5HYB&
%,//2)0$7(5,$/3DJHRI
,WHP
&LUUXV31
5HY
'HVFULSWLRQ
4W\
5HIHUHQFH'HVLJQDWRU
0)*
0)*31
1R
WHV
1
070-00157-Z1
A
DIODE RECT BRIDGE 600V 4A NPb GBU
1
BR1
MICRO COMMERCIAL CO
GBU4J-BP
2
011-00042-Z1
A
CAP 2200pF ±10% 2000V CER NPb RAD
2
C1 C2
MURATA
DEBB33D222KA2B
3
011-00055-Z1
A
CAP 0.22uF ±20% 305V PLY FLM NPb TH
0
C
3
EPCOS
B32923C3224M
NO POP
4
011-00040-Z1
A
CAP 0.47uF ±20% 305V PLY FLM NPb TH
0
C
4
EPCOS
B32922C3474M
NO POP
5
013-00034-Z1
A
CAP 0.33uF ±10% 630V POLY NPb RAD
1
C
5
PANASONIC
ECQE6334KF
6
012-00186-Z1
A
CAP 47UF ±20% 250V ELEC NPb RAD
2
C6 C14
NICHICON
UVZ2E470MHD
7
001-05280-Z1
A
CAP 33pF ±5% 50V C0G NPb 1206
1
C
7
KEMET
C1206C330J5GAC
8
001-05783-Z1
A
CAP 330pF ±10% 50V C0G NPb 1206
0
C
8
KEMET
C1206C331K5GAC
NO POP
9
001-10233-Z1
A
CAP 4.7uF ±20% 25V X7R NPb 1206
1
C
9
TDK
C3216X7R1E475M
10
001-05542-Z1
A
CAP 100pF ±5% 50V C0G NPb 1206
1
C10
KEMET
C1206C101J5GAC
11
001-06276-Z1
A
CAP 2200pF ±10% 50V X7R NPb 1206
0
C11 C12
KEMET
C1206C222K5RAC
NO POP
12
011-00064-Z1
A
CAP 0.22uF ±20% 330V PLY FLM NPb TH
1
C13
EPCOS
B32912B3224M
ECO840
13
070-00132-Z1
A
DIODE RECT 800V 1A 200mA NPb DO-41
1
D
1
DIODES INC
1N4006G-T
14
070-00166-Z1
A
DIODE RECT 600V 4A ULT FST NPb SMC
1
D
2
ON SEMICONDUCTOR
MURS360T3G
15
070-00001-Z1
A
DIODE SS 75V 500mW NPb SOD80
1
D
4
DIODES INC
LL4148
16
180-00022-Z1
A
FUSE 3.15A TLAG IEC NPb SHORT TR5
1
F2
LITTLE FUSE
37213150411
17
311-00019-Z1
A
HTSNK W LOCK TAB .5" TO220 NPb
1
HS1
AAVID THERMALLOY
6021PBG
REQUIRES 1 SCREW, 300-00025-Z1, 1 WASHER, 301- 00013-Z1, 1 NUT, 302-00007-Z1 OR MOUNTING KIT 4880G AAVID
18
115-00014-Z1
A
HDR 2x1 ML .1" 062BD ST GLD NPb TH
2
J1 J3
SAMTEC
TSW-102-07-G-S
19
110-00301-Z1
A
CON 3POS TERM BLK 5.08mm SPR NPb RA
2
J5 J6
WEIDMULLER
1716030000
20
110-00302-Z1
A
CON 2POS TERM BLK 5.08mm SPR NPb RA
1
J7
WEIDMULLER
1716020000
21
080-00013-Z1
A
WIRE 24 AWG SOLID PVC INS BLK NPb
6.000
JMP1 JMP2 JMP3 JMP4 W2
ALPHA WIRE COMPANY
3050/1 BK005
SEE ASSY DWG FOR LENGT
H
22
050-00039-Z1
A
XFMR 5mH 1:1 1500Vrms 4PIN NPb TH
1
L1
PREMIER MAGNETICS
TSD-2796
23
050-00050-Z1
A
XFMR 380uH 10% .265O NPb TH
1
L2
RENCO
RLCS-1005
24
040-00127-Z1
A
IND 1mH 1.3A ±15% TOR VERT NPb TH
1
L3
BOURNS
2124-V-RC
25
040-00127-Z1
A
IND 1mH 1.3A ±15% TOR VERT NPb TH
0
L4
BOURNS
2124-V-RC
NO POP
26
050-00039-Z1
A
XFMR 5mH 1:1 1500Vrms 4PIN NPb TH
0
L5
PREMIER MAGNETICS
TSD-2796
NO POP
27
050-00047-Z1
A
XFMR COMMON MODE CHOKE 1.3 A TH NPb
0
L6 L7
RENCO
RL-4400-2-4.00
NO POP
28
304-00004-Z1
A
SPCR STANDOFF 4-40 THR .500"L NPb
4
MH1 MH2 MH3 MH4
KEYSTONE
2203
REQUIRES SCREW 4-40X5X16" PH STEEL 300-00025- Z1
29
071-00107-Z1
A
TRAN MOSFT nCH 11A 600V NPb TO220FP
1
Q
4
ST MICROELECTRONICS
STF13NM60N
30
020-06337-Z1
A
RES 24.9 OHM 1/4W ±1% NPb 1206 FILM
1
R
1
DALE
CRCW120624R9FKEA
31
020-02502-Z1
A
RES 100 OHM 1/4W ±1% NPb 1206 FILM
1
R
2
DALE
CRCW1206100RFKEA
32
020-02616-Z1
A
RES 1k OHM 1/4W ±1% NPb 1206 FILM
0
R
3
DALE
CRCW12061K00FKEA
NO POP
33
020-02273-Z1
A
RES 0 OHM 1/4W NPb 1206 FILM
2
R4 R6
DALE
CRCW12060000Z0EA
34
020-06390-Z1
A
RES 17.8K OHM 1/4W ±1% NPb 1206
1
R
5
DALE
CRCW120617K8FKEA
35
020-06310-Z1
A
RES 20K OHM 1/4W ±1% NPb 1206 FILM
1
R
7
DALE
CRCW120620K0FKEA
36
030-00091-Z1
A
RES 0.1 OHM 2W ±1% WW NPb AXL
0
R
8
VISHAY
G003R1000FE7080
NO POP
37
030-00091-Z1
A
RES 0.1 OHM 2W ±1% WW NPb AXL
1
R
9
VISHAY
G003R1000FE7080
38
020-06356-Z1
A
RES 1.15M OHM 1/4W ±1% NPb 1206
6
R10 R11 R12 R13 R15 R16
DALE
CRCW12061M15FKEA
39
020-02616-Z1
A
RES 1k OHM 1/4W ±1% NPb 1206 FILM
1
R14
DALE
CRCW12061K00FKEA
40
020-06391-Z1
A
RES 1.78K OHM 1/4W ±1% NPb 1206
1
R17
DALE
CRCW12061K78FKEA
41
020-06372-Z1
A
RES 0.24 OHM 1W ±1% NPb 2512
0
R18 R22
PANASONIC
ERJ1TRQFR24U
NO POP
42
030-00080-Z1
A
RES 100K 1W ±5% MTL FLM NPb AXL
2
R19 R20
XICON
294-100K-RC
43
036-00015-Z1
A
VARISTOR 470V RMS 14MM NPb RAD
0
RV1
EPCOS
S14K300
NO POP
44
110-00045-Z1
A
CON TEST PT .1"CTR TIN PLAT NPb BLK
7
TP2 TP3 TP4 TP5 TP6 TP7 TP8
KEYSTONE
5001
45
065-00331-Z3
A2
IC CRUS LPWR FACTOR CORR NPb SOIC8
1
U
1
CIRRUS LOGIC
CS1601-FSZ/A2
ECO840
46
080-00002-01
A
WIRE 28/1 AWG, KYNAR MOD, 500FT
2.000
W1
SQUIRES
L 500 UL1422 28/1 BLU
ADD LENGTH TO BOM QUANTITY IN INCHES
47
080-00040-Z1
A
WIRE 16AWG SOLID PVC INS BLK NPb
4.000
W3
ALPHA WIRE COMPANY
3057/1 BK005
ADD LENGTH TO BOM QUANTITY IN INCHES
48
311-00025-Z1
A
HTSNK TO220 MOUNTING KIT NPb
1
XHS1
AAVID THERMALLOY
4880G
INCLUDES ALL MOUNTING HARDWARE
49
300-00025-Z1
A
SCREW 4-40X5/16" PH MACH SS NPb
4
XMH1MXMH2 XMH3 XMH4
BUILDING FASTENERS
PMSSS 440 0031 PH
SCREWS FOR STANDOFFS
50
240-00466-Z1
C
PCB CDB1601-120W-Z-NPb
1
CIRRUS LOGIC
240-00466-Z1
ECO805/826/840
51
603-00466-Z1
C
ASSY DWG CDB1601-120W-Z-NPb
REF
CIRRUS LOGIC
603-00466-Z1
ECO805/826/840
52
600-00466-Z1
C
SCHEM CDB1601-120W-Z-NPb
REF
CIRRUS LOGIC
600-00466-Z1
ECO805/826/840
53
422-00013-01
C
LBL SUBASSY PRODUCT ID AND REV
1
CIRRUS LOGIC
422-00013-01
