CDB150x-01
DS927DB4 5
3. BILL OF MATERIALS
&,5586/2*,& &'%;B5HYB&
%,//2)0$7(5,$/3DJHRI
,WHP
&LUUXV31
5HY
'HVFULSWLRQ
4W\
5HIHUHQFH'HVLJQDWRU
0)*
0)*31
1R
WHV
1
070-00157-Z1
A
DIODE RECT BRIDGE 600V 4A NPb GBU
1
BR1
MICRO COMMERCIAL CO
GBU4J-BP
2
011-00042-Z1
A
CAP 2200pF ±10% 2000V CER NPb RAD
2
C1 C2
MURATA
DEBB33D222KA2B
3
011-00055-Z1
A
CAP 0.22uF ±20% 305V PLY FLM NPb TH
0
C
3
EPCOS
B32923C3224M
DO NOT POPULATE
4
011-00064-Z1
A
CAP 0.22uF ±20% 330V PLY FLM NPb TH
1
C
4
EPCOS
B32912B3224M
ECO0841
5
011-00040-Z1
A
CAP 0.47uF ±20% 305V PLY FLM NPb TH
0
C
5
EPCOS
B32922C3474M
DO NOT POPULATE
6
013-00034-Z1
A
CAP 0.33uF ±10% 630V POLY NPb RAD
1
C
6
PANASONIC
ECQE6334KF
7
012-00191-Z1
A
CAP 100UF ±20% 450V ELEC NPb RAD
1
C
7
NICHICON
UVZ2W101MRD
8
000-00009-Z1
A
NO POP CAP NPb 1206
0
C8 C9
NO POP
NP-CAP-1206
DO NOT POPULATE
9
001-10233-Z1
A
CAP 4.7uF ±20% 25V X7R NPb 1206
1
C10
TDK
C3216X7R1E475M
10
001-05280-Z1
A
CAP 33pF ±5% 50V C0G NPb 1206
1
C11
KEMET
C1206C330J5GAC
11
001-05542-Z1
A
CAP 100pF ±5% 50V C0G NPb 1206
1
C12
KEMET
C1206C101J5GAC
12
001-06035-Z1
A
CAP 1000pF ±5% 50V X7R NPb 1206
1
C13
KEMET
C1206C102J5RAC
13
001-06035-Z1
A
CAP 1000pF ±5% 50V X7R NPb 1206
0
C14 C15
KEMET
C1206C102J5RAC
DO NOT POPULATE
14
110-00301-Z1
A
CON 3POS TERM BLK 5.08mm SPR NPb RA
2
CON1 CON3
WEIDMULLER
1716030000
15
110-00302-Z1
A
CON 2POS TERM BLK 5.08mm SPR NPb RA
1
CON2
WEIDMULLER
1716020000
16
070-00132-Z1
A
DIODE RECT 800V 1A 200mA NPb DO-41
1
D
1
DIODES INC
1N4006G-T
17
070-00154-Z1
A
DIODE RECT 600V 4A NPb DO-201AD TH
1
D
2
ON SEMICONDUCTOR
MUR460G
18
070-00001-Z1
A
DIODE SS 75V 500mW NPb SOD80
1
D
3
DIODES INC
LL4148
19
180-00025-Z1
A
FUSE 4A SLO BLO 250V NPb RAD
1
F
1
BELFUSE
RST 4
20
311-00019-Z1
A
HTSNK W LOCK TAB .5" TO220 NPb
1
HS1
AAVID THERMALLOY
6021BG
REQUIRES 1 SCREW, 300-00025- Z1, 1 WASHER, 301-00013-Z1, 1 NUT, 302-00007-Z1
21
080-00013-Z1
A
WIRE 24 AWG SOLID PVC INS BLK NPb
1
JP1
ALPHA WIRE COMPANY
3050/1 BK005
SEE ASSY DWG FOR LENGTH
22
050-00039-Z1
A
XFMR 5mH 1:1 1500Vrms 4PIN NPb TH
0
L
1
PREMIER MAGNETICS
TSD-2796
DO NOT POPULATE, SHORT PIN 1- 2 & PIN 3-4 with 28 AWG wire
23
050-00039-Z1
A
XFMR 5mH 1:1 1500Vrms 4PIN NPb TH
1
L
2
PREMIER MAGNETICS
TSD-2796
24
040-00127-Z1
A
IND 1mH 1.3A ±15% TOR VERT NPb TH
1
L
3
BOURNS
2124-V-RC
25
040-00127-Z1
A
IND 1mH 1.3A ±15% TOR VERT NPb TH
0
L
4
BOURNS
2124-V-RC
DO NOT POPULATE, SHORT WITH AWG28 WIRE
26
050-00051-Z1
A
XFMR 380uH 10:1 PFC BOOST NPb TH
1
L
5
RENCO
RLCS-1007
ECO806
27
304-00004-Z1
A
SPCR STANDOFF 4-40 THR .500"L NPb
4
MH1 MH2 MH3 MH4
KEYSTONE
2203
REQUIRES SCREW 4-40X5X16" PH STEEL 300-00025-Z1
28
036-00008-Z1
A
THERM 30 OHM 1.5A 5% NPb RAD
0
NTC1
GE SENSING
CL-210
DO NOT POPULATE, SHORT WITH 28 AWG WIRE
29
036-00008-Z1
A
THERM 30 OHM 1.5A 5% NPb RAD
0
NTC2
GE SENSING
CL-210
DO NOT POPULATE, SHORT WITH AWG28 WIRE
30
071-00083-Z1
A
TRAN MOSFET nCH 12A 500V NPb TO220
1
Q
1
ST MICROELECTRONICS
STP12NM50FP
31
020-06374-Z1
A
RES 1M OHM 1/4W ±1% NPb 1206
6
R1 R2 R3 R13 R14 R15
DALE
CRCW12061M00FKEA
32
000-00004-Z1
A
NO POP RES NPb 1206
0
R4 R5 R17 R21 R22
NO POP
NP-RES-1206
DO NOT POPULATE
33
020-06376-Z1
A
RES 48.7K OHM 1/4W ±1% NPb 1206
1
R
6
DALE
CRCW120648K7FKEA
ECO819
34
020-06389-Z1
A
RES 4.7 OHM 1/4W ±1% NPb 1206
1
R
7
DALE
CRCW12064R70FKEA
ECO805
35
020-06310-Z1
A
RES 20K OHM 1/4W ±1% NPb 1206 FILM
1
R
8
DALE
CRCW120620K0FKEA
36
030-00092-Z1
A
RES 0.1 OHM 3W ±1% WW ISEN NPb AXL
1
R
9
OHMITE
13FR100E
37
021-01186-Z1
A
RES 1 OHM 1W ±5% NPb 2512 FILM
0
R10
DALE
CRCW25121R00JNEG
DO NOT POPULATE
38
020-02616-Z1
A
RES 1k OHM 1/4W ±1% NPb 1206 FILM
2
R11 R20
DALE
CRCW12061K00FKEA
39
020-02273-Z1
A
RES 0 OHM 1/4W NPb 1206 FILM
3
R12 R16 R23
DALE
CRCW12060000Z0EA
40
020-06391-Z1
A
RES 1.78K OHM 1/4W ±1% NPb 1206
1
R18
DALE
CRCW12061K78FKEA
