BILL OF MATERIAL (Page 2 of 2)
Item
Cirrus P/N
Rev
Description
Qty
Reference Designator
MFG
MFG P/N
Notes
41
020-02502-Z1
A
RES 100 OHM 1/4W ±1% NPb 1206 FILM
1
R19
DALE
CRCW1206100RFKEA
42
110-00025-Z1
A
CON TEST PT .1" TIN PLATE WHT NPb
7
TP2 TP3 TP4 TP5 TP6 TP7 TP8
KEYSTONE
5002
43
065-00328-Z3
A2
IC CRUS LPWR FACTOR CORR NPb SOIC8
1
U
1
CIRRUS LOGIC
CS1501-FSZ/A2
ECO0841
44
065-00276-Z5
C1
IC CRUS LPWR FACTOR CORR NPb SOIC8
0
U
2
CIRRUS LOGIC
CS1500-FSZ/C1
DO NOT POPULATE
45
036-00006-Z1
A
VARISTOR 300V 400pF 14mm NPb RAD
1
V
Z
LITTELFUSE
V300LA20AP
46
311-00025-Z1
A
HTSNK TO220 MOUNTING KIT NPb
1
XHS1
AAVID THERMALLOY
4880G
INCLUDES ALL MOUNTING HARDWARE
47
300-00025-Z1
A
SCREW 4-40X5/16" PH MACH SS NPb
4
XMH1 XMH2 XMH3 XMH4
BUILDING FASTENERS
PMSSS 440 0031 PH
48
422-00013-01
C
LBL SUBASSY PRODUCT ID AND REV
1
CIRRUS LOGIC
422-00013-01
49
422-00037-01
C
LBL SUBASSY PRODUCT NUMBER
1
CIRRUS LOGIC
422-00037-01
SEE ASSYDWG FOR LABEL PLACEMENT
50
603-00473-Z1
C
ASSY DWG CDB150X-0X-Z-NPb
REF
CIRRUS LOGIC
603-00473-Z1
ECO805/ECO824/ECO0841
51
240-00473-Z1
C
PCB CDB150X-0X-Z-NPb
1
CIRRUS LOGIC
240-00473-Z1
ECO805/ECO824/ECO0841
52
600-00473-Z2
C
SCHEM CDB150X-01-Z-NPb
REF
CIRRUS LOGIC
600-00473-Z2
ECO819/EC O0841
080-00036-Z1
A
WIRE 22AWG 19/34 STR BLK 105C NP
1
ALPHA WIRE COMPANY
5855 BK005
ECO824, SEE ASSY DWG
080-00002-01
A
WIRE 28/1 AWG, KYNAR MOD, 500FT
1
SQUIRES
L 500 UL1422 28/1 BLU
ECO824, SEE ASSY DWG
