DS206DB2 11
CDB8952
Crystal LAN™ 10Base-T and 100Base-X Transceiver
CIRRUS LOGIC ADVANCED PRODUCT DATABOOK
CDB8952 BILL OF MATERIALS
Ref. Des. Description Manufacturer Part Number
C1, C3, C4, C26 Cap, Tant, 10uF, 20V, 20%, 6032 Kemet T491C106M020AS
C2, C5-C17, C19-C25, C37,
C38, C44 Cap, X7R, 0.1uF, 50V, 10%, 0805 Kemet C0805C104K5RAC
C27, C28 Cap, Tant, 1uF, 20V, 20%, 3216 Kemet T491A105M020AS
C46 Cap, X7R, 0.01uF, 2KV, 20%, 2225 AVX 2225GC103MA11A
D9, D10 Diode, BAS16LT1, SOT23 Motorola BAS16LT1
HDR1, HDR34, HDR35 Header, 2x1, 0.1” centers
HDR4-HDR7, HDR42, HDR43 Header, 3x1, 0.1” centers
HDR15 Header, 10x2, 0.1” centers
J1, J5, J6 Conn, SMB Amp 413990-1
J2 Conn, RJ45, shielded Amp 558575-1
J13 Conn, MII Fujitsu FCN238P040-G/S
LED1-LED8 LED, Green, SMT Panasonic LN1351C-TR
L1, L2 Ferrite Bead, 1206 TDK CB70-1812
R1 Res, 63.4
Ω
, 1%, 1/10W, 0805 Bourns CR0805-FX-63R4-E
R2-R4 Res, 130
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-131-E
R5 Res, 1.5K
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-152-E
R6, R32-R35, R46-R49, R71 Res, 33
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-330-E
R7 Res, 68
Ω
, 1%, 1/10W, 0805 Bourns CR0805-FX-68R0-E
R8 Res, 4.99K
Ω
, 1%, 1/10W, 0805 Bourns CR0805-FX-4991-E
R9, R13, R14, R16, R18, R22,
R63, R64, R67-R69, R77-R80 Res, 33K
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-333-E
R10, R15, R17, R19, R21, R23,
R50-R59, R70, R72 Res, 4.7K
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-472-E
R11 Res, 1K
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-102-E
R12, R73-R76 Res, 49.9
Ω
, 1%, 1/10W, 0805 Bourns CR0805-FX-49R9-E
R20 Res, 18K
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-183-E
R24-R29 Res, 51
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-510-E
R30 Res, 191
Ω
, 1%, 1/10W, 0805 Bourns CR0805-FX-1910-E
R31, R60, R61 Res, 82
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-820-E
R36-R43 Res, 680
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-681-E
R44, R45 Res, 75
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-750-E
R62, R97, R99-R113 Res, 0
Ω
, 1A, 0805 Bourns CR0805-JX-000-E
R65, R66 Res, 100
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-102-E
R81 Res, 390
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-391-E
R98 Res, 10K
Ω
, 5%, 1/10W, 0805 Bourns CR0805-JX-103-E
S1, S2 Switch, NO Push-button C&K PTS645TL50
S3 Switch, 5-position DIP CTS CTS208-5
TP1, TP2, TP4 Testpoint
T1 Transformer, Isolation See page 5
U2 IC, CS8952, TQFP100 Cirrus CS8952-CQ
U4 IC, 74HC14, SO14 TI SN74HC14D
U6 IC, HFBR-5103 HP HFBR-5103
Y1 Xtal, 25.00MHz, HC49U See page 5
