Cirrus Logic CDB5534U User Manual
Features, General description, Usb communication with pc
Copyright
© Cirrus Logic, Inc. 2006
(All Rights Reserved)
AIN1+
AIN1-
AIN2+
AIN2-
CRYSTAL
4.9152 MHz
CS5534
A1
A0
SCLK
SDO
SDI
CS
C8051F320
Microcontroller
RESET
CIRCUITRY
Interface Header
AIN1+
AIN1-
AIN2+
AIN2-
AIN3+
AIN3-
AIN3+
AIN3-
AIN4+
AIN4-
AIN4+
AIN4-
VREF-
VREF+
VREF
Source
Select
LT1019
VREF+
VREF-
VD+
VA-
VA+
GND
+5 V
USB
CONNECTOR
CDB5534U
CDB5534U Evaluation Board and Software
Features
z
USB Communication with PC
z
On-board Microcontroller
z
On-board Voltage Reference
z
Evaluation Software
– Register Setup & Chip Control
– FFT Analysis
– Time Domain Analysis
– Noise Histogram Analysis
z
Interface Header for External Microcontroller
General Description
The CDB5534U is an inexpensive tool designed to eval-
uate the functionality and performance of the CS5534.
The CS5534 datasheet should be read and consulted
when using the CDB5534U evaluation board.
The evaluation board includes a C8051F320 microcon-
troller with a USB interface. The microcontroller controls
the serial communication between the evaluation board
and the PC via the firmware, enabling quick and easy ac-
cess to all of the CS5534’s registers and functions.
The CDB5534U includes software for Data Capture,
Time Domain Analysis, Histogram Analysis, and Fre-
quency Domain Analysis.
ORDERING INFORMATION
CDB5534U
Evaluation Board
NOV ‘06
DS289DB6
