26 DS625F5
CS5364
Table 9. Frequencies for 96 kHz Sample Rate using TDM
Table 10. Frequencies for 96 kHz Sample Rate using TDM
Table 11. Frequencies for 192 kHz Sample Rate using TDM
Table 12. Frequencies for 192 kHz Sample Rate using TDM
TDM MASTER DSM Fs = 96 kHz
MCLK Divider 4 3 2 - -
MCLK (MHz) 49.152 36.864 24.567 - -
SCLK (MHz) 24.576 24.576 24.576 - -
MCLK/FS Ratio 512 384 256 - -
SCLK/FS Ratio 256 256 256 - -
TDM SLAVE DSM Fs = 96 kHz
MCLK Divider 4 3 2 1.5 1
MCLK (MHz) 49.152 36.864 24.567 18.384 12.288
SCLK (MHz) 24.576 24.576 24.576 24.576 24.576
MCLK/FS Ratio 512 384 256 192 128
SCLK/FS Ratio 256 256 256 256 256
TDM MASTER QSM Fs = 192 kHz
MCLK Divider 4 - - - -
MCLK (MHz) 49.152 - - - -
SCLK (MHz) 49.152 - - - -
MCLK/FS Ratio 256 - - - -
SCLK/FS Ratio 256 - - - -
TDM SLAVE QSM Fs = 192 kHz
MCLK Divider 4 3 2 1.5 1
MCLK (MHz) 49.152 36.864 24.567 18.384 12.288
SCLK (MHz) 49.152 49.152 49.152 49.152 49.152
MCLK/FS Ratio 256 192 128 96 64
SCLK/FS Ratio 256 256 256 256 256
