ANALOG PERFORMANCE (AUTOMOTIVE)
Test Conditions (unless otherwise specified). VA = 5.25 to 4.75 V, VD = 5.25 to 3.14 V, VLS = VLC = 5.25 to 1.71 V
and T
A
= -40° to +85° C. Full-scale input sine wave. Measurement Bandwidth is 10 Hz to 20 kHz.
Parameter Symbol Min Typ Max Unit
Single-Speed Mode Fs = 48 kHz
Dynamic Range
A-weighted
unweighted
106
103 114
111
- dB
Total Harmonic Distortion + Noise -1 dB
referred to typical full scale -20 dB
-60 dB THD+N -
-105
-91
-51
-97
-
-45
dB
Double-Speed Mode Fs = 96 kHz
Dynamic Range
A-weighted
unweighted
40 kHz bandwidth unweighted
106
103
-
114
111
108
- dB
Total Harmonic Distortion + Noise -1 dB
referred to typical full scale -20 dB
-60 dB
40 kHz bandwidth -1 dB
THD+N -
-105
-91
-51
-102
-97
-
-45
-
dB
Quad-Speed Mode Fs = 192 kHz
Dynamic Range
A-weighted
unweighted
40 kHz bandwidth unweighted
106
103
-
114
111
108
- dB
Total Harmonic Distortion + Noise -1 dB
referred to typical full scale -20 dB
-60 dB
40 kHz bandwidth -1 dB
THD+N -
-105
-91
-51
-102
-97
-
-45
-
dB
Dynamic Performance for All Modes
Interchannel Isolation - 110 - dB
DC Accuracy
Interchannel Gain Mismatch - 0.1 - dB
Gain Error -7 - 7 %
Gain Drift -

100 - ppm/°C
Offset Error HPF enabled
HPF disabled
0
-
-
- -
100
LSB
Analog Input Characteristics
Full-scale Input Voltage 1.02*VA 1.13*VA 1.24*VA Vpp
Input Impedance (Differential) 250 - k 
Common Mode Rejection Ratio CMRR - 82 - dB
