4.4 CHANNEL B VOLUME CONTROL - ADDRESS 04H
4.4.1 Mute (Bit 7)
Function:
The Digital-to-Analog converter output will mute when enabled. The common mode voltage on the
output will be retained. The muting function is effected, similiar to attenuation changes, by the Soft
and Zero Cross bits in the Volume and Mixing Control register. The MUTEC pin for that channel will
go active during the mute period if the Mute function is enabled. Both the AMUTEC and BMUTEC
will go active if either MUTE register is enabled and the MUTEC A = B bit (register 5) is enabled.
4.4.2 Volume Control (Bits 6:0)
Function:
The digital volume control allows the user to attenuate the signal in 1 dB increments from 0 to -119
dB. Volume settings are decoded as shown in Table 7. The volume changes are implemented as
dictated by the Soft and Zero Cross bits in the Volume and Mixing Control register. All volume settings
less than - 119 dB are equivalent to enabling the Mute bit.
4.5 MODE CONTROL 2 - ADDRESS 05H
4.5.1 Invert Signal Polarity (Bits 7:6)
Function:
When set, this bit inverts the signal polarity.
4.5.2 Control Port Enable (Bit 5)
Function:
This bit defaults to 0, allowing the device to power-up in Stand-Alone mode. The Control port mode
can be accessed by setting this bit to 1. This will allow the operation of the device to be controlled by
the registers and the pin definitions will conform to Control Port Mode. To accomplish a clean power-
up, the user should write 11h to register 5 within 10 ms following the release of Reset.
4.5.3 Power Down (Bit 4)
Function:
The device will enter a low-power state whenever this function is activated. The power-down bit de-
faults to ‘enabled’ on power-up and must be disabled before normal operation will begin. The contents
of the control registers are retained when the device is in power-down.
4.5.4 AMUTEC = BMUTEC (Bit 3)
Function:
When this function is enabled, the individual controls for AMUTEC and BMUTEC are internally con-
nected through a AND gate prior to the output pins. Therefore, the external AMUTEC and BMUTEC
pins will go active only when the requirements for both AMUTEC and BMUTEC are valid.
7 6 5 4 3 2 1 0
MUTE VOL6 VOL5 VOL4 VOL3 VOL2 VOL1 VOL0
7 6 5 4 3 2 1 0
INVERT_A INVERT_B CPEN PDN MUTEC A = B FREEZE MCLK Divide Reserved
