18 10 L1,L2,L3,L4,L5,L6,L7,L8,
L9,L10 TDK HF50ACB321611-T IND, FBEAD, 1206, 31@100MHz, 25%
19 1 P1 NONE NONE CNR BUS CONNECTOR
20 2 R2,R1 PHILIPS 9C08052A47R0J RES, SO, 0805, 47, 5%, 1/10W, METAL FILM
21 14 R4,R6,R8,R10,R13,R16,
R18,R19,R20,R22,R24,
R25,R26,R27 PHILIPS 9C08052A6801F RES, SO, 0805, 6.8K, 1%, 1/10W, METAL FILM
22 3 R5,R9,R12 PHILIPS 9C08052A1003J RES, SO, 0805, 100K, 5%, 1/10W, METAL FILM
23 1 R14 PHILIPS 9C08052A2201J RES, SO, 0805, 2.2K, 5%, 1/10W, METAL FILM
24 1 R15 PHILIPS 9C08052A1501J RES, SO, 0805, 1.5K, 5%, 1/10W, METAL FILM
25 6 R21,R29,R34,R35,R40,R41 PHILIPS 9C08052A4702J RES, SO, 0805, 47K, 5%, 1/10W, METAL FILM
26 1 R23 PHILIPS 9C08052A4701J RES, SO, 0805, 4.7K, 5%, 1/10W, METAL FILM
27 2 R28,R55 PHILIPS 9C08052A0R00J RES, SO, 0805, 0, 5%, 1/10W, METAL FILM
28 4 R30,R31,R36,R37 PHILIPS 9C08052A5600J RES, SO, 0805, 560, 5%, 1/10W, METAL FILM
29 4 R32,R33,R38,R39 PHILIPS 9C08052A2703J RES, SO, 0805, 270K, 5%, 1/10W, METAL FILM
30 2 R45,R44 PHILIPS 9C08052A2203J RES, SO, 0805, 220K, 5%, 1/10W, METAL FILM
31 3 R48,R49,R56 PHILIPS 9C08052A1002J RES, SO, 0805, 10K, 5%, 1/10W, METAL FILM
32 1 R50 PHILIPS 9C08052A8201J RES, SO, 0805, 8.2K, 5%, 1/10W, METAL FILM
33 3 R51,R52,R53 NO POP NO POP NO POP
34 1 R54 PHILIPS 9C08052A1001J RES, SO, 0805, 1K, 5%, 1/10W, METAL FILM
35 6 TP1,TP2,TP3,TP4,TP5,TP6 KEYSTONE 5015 mini SMT test point
36 1 U1 Cirrus Logic CS4202-JQ IC, TQFP, AC '97 2.2 SERIAL CODEC W/ HP
AMP + SRC
37 2 U2,U3 Cirrus Logic CS4334-KS IC, SO, SOIC8, STEREO DAC, 24 BITS
