Page 30: 9 ball wlcsp

CS35L01/03
30
DS909F1
8. PACKAGING AND THERMAL INFORMATION
8.1
Package Drawings and Dimensions
Note:
20. Dimensioning and tolerance per ASME Y 14.5M-1994.
INCHES
MILLIMETERS
NOTE
DIM
MIN
NOM
MAX
MIN
NOM
MAX
X
0.047
0.048
0.049
1.195
1.215
1.235
Y
0.047
0.048
0.049
1.195
1.215
1.235
b
0.009
0.011
0.012
0.240
0.270
0.300
e
-
0.015
-
-
0.400 BSC
-
A
0.018
0.020
0.022
0.475
0.515
0.555
A1
0.006
0.007
0.008
0.175
0.190
0.205
A2
0.012
0.013
0.014
0.300
0.325
0.350
JEDEC #: MO-220
Controlling Dimension is Millimeters.
A2
Y
X
b
e
e
A1
A
9 solder spheres
9 BALL WLCSP
