Cdb3308, Evaluation board for cs3308

Copyright
© Cirrus Logic, Inc. 2006
(All Rights Reserved)
Evaluation Board for CS3308
Features
Single-ended Analog Inputs
Single-ended Analog Outputs
Supports AC and DC-Coupled Analog I/O
Flexible Serial Control I/O Headers
–
Serial Control Input Header to
Accommodate On-board and External
Serial Controllers
–
Serial Control Output Headers for
“Chaining” Serial Control Across Multiple
CDB3308 Evaluation Boards
–
3.3 V Logic Interface Level
Demonstrates Recommended Layout and
Grounding Arrangements
Minimal Power Supply Requirements
–
±5 V and Ground
Windows
®
Compatible Software Interface
–
Easy and Intuitive Graphical Interface to
Channel and Master Volume Controls
–
Supports USB and RS-232 PC
Connectivity
Description
The CDB3308 evaluation board is an excellent means
for evaluating the CS3308 analog volume control. Eval-
uation requires an analog signal source and analyzer,
power supplies, and a Windows PC compatible
computer.
Standard RCA phono jacks are provided to easily inter-
face external analog signals with the evaluation board.
Each of the CS3308’s inputs and outputs may be inde-
pendently AC or DC-coupled to their respective I/O
connectors.
The Windows software provides a GUI to make config-
uration of the CDB3308 easy. The software
communicates through the PC’s USB or Serial port to
configure the control port registers so that all features of
the CS3308 can be evaluated.
As an alternative to the serial control provided via a PC,
the evaluation board may be configured to accept exter-
nal control signals for operation in a user application
during system development.
To facilitate multi-CS3308 system design efforts, head-
ers are provided for connecting serial control signals
between multiple CDB3308 evaluation boards.
ORDERING INFORMATION
CDB3308
Evaluation Board
CS3308
8-Channel
Digitally Controlled
Analog Volume Control
8-Channel
Passive
Inputs
AC/DC
Coupling
AC/DC
Coupling
8-Channel
Passive
Outputs
USB/RS232
PC Interface
PC or External
Serial Control Input
External
Serial Control Output
CDB3308
MAY '06
DS702DB2
