CS3318
7.18
Group 2 Chip Address 19h
7.18.1
Group 2 Chip Address (Bits 7:1)
SPI Mode Default = 1000000b
I²C Mode Default = See
Function:
These bits set the Group 2 chip address, and may be modified at any time. See
trol Configuration” on page 23
and
“I²C/SPI Serial Control Formats” on page 27
for more information.
7.18.2
Enable Group 2 Address (Bit 0)
Default = 0
Function:
This bit controls the device’s recognition of the Group 2 address. When set, the device will respond
to serial communication when addressed with the Group 2 address. When cleared, the device will ig-
nore all serial communication when addressed with the Group 2 address.
7.19
Group 1 Chip Address 1Ah
7.19.1
Group 1 Chip Address (Bits 7:1)
SPI Mode Default = 1000000b
I²C Mode Default = See
Function:
These bits set the Group 1 chip address, and may be modified at any time. See
trol Configuration” on page 23
and
“I²C/SPI Serial Control Formats” on page 27
for more information.
7.19.2
Enable Group 1 Address (Bit 0)
Default = 0
Function:
This bit controls the device’s recognition of the Group 1 address. When set, the device will respond
to serial communication when addressed with the Group 1 address. When cleared, the device will ig-
nore all serial communication when addressed with the Group 1 address.
7
6
5
4
3
2
1
0
G2_Addr6
G2_Addr5
G2_Addr4
G2_Addr3
G2_Addr2
G2_Addr1
G2_Addr0
EnG2Addr
7
6
5
4
3
2
1
0
G1_Addr6
G1_Addr5
G1_Addr4
G1_Addr3
G1_Addr2
G1_Addr1
G1_Addr0
EnG1Addr
