CS3004

DS719F2

3

1. CHARACTERISTICS AND SPECIFICATIONS

1.1

5 V Electrical Characteristics

V+ = +5 V, ±5%; V- = 0V; VCM = 2.5 V; Unless otherwise noted, T

A

= 25º C (See Note 1).

Notes: 1. Symbol “ denotes specification applies over -40 to +125

°

C.

2. This parameter is guaranteed by design and/or laboratory characterization.
3. Guaranteed within the output limits of (V+ – 0.2 V) to (V- + 0.2 V).
4. Specifies the worst case drive voltage relative to the supply rail under stated load conditions.

Parameter

Min

Typ

Max

Unit

Input Offset Voltage

(

Note 2

)

-

±2

±10

µV

Average Input Offset Drift

(

Note 2

)

-

±0.01

±0.05

µV/ºC

Input Bias Current

-
-

±170

-

±250

±1.5

pA
nA

Input Offset Current

-
-

±340

-

±500

±3.0

pA
nA

Input Noise Voltage Density

R

S

= 100

Ω, f

0

= 1 Hz

R

S

= 100

Ω, f

0

= 1 kHz

-
-

17
17

-
-

Input Noise Voltage

0.1 to 10 Hz

-

350

-

nV

p-p

Input Noise Current Density

f

0

= 1 Hz

-

100

-

Input Noise Current

0.1 to 10 Hz

-

1.9

pA

p-p

Input Voltage Range

(

Note 2

)

V-

-

V+

V

Common Mode Rejection Ratio (dc)

110

120

-

dB

Power Supply Rejection Ratio

110

130

-

dB

Large Signal Voltage Gain
(

Note 3

)

R

L

= 2 k

Ω to V+/2

-

120

150
150

-
-

dB
dB

Output Voltage Swing

R

L

= 2 k

Ω to V+/2

(

Note 4

) R

L

= 100 k

Ω to V+/2

(V+ – 100)

(V+ – 10)

-
-

(V- + 100 )

(V- + 10)

mV
mV

Slew Rate

R

L

= 2 k, 100 pF

0.25

-

V/µs

Overload Recovery Time

-

25

-

µs

Supply Current

-

2.0

2.5

mA

Oscillator Frequency

-

150

-

kHz

Input Capacitance

Differential

Common Mode

-
-

1.5

10

-
-

pF
pF

nV/ Hz
nV/ Hz

fA/ Hz
