CRD1615A-8W
DS1043RD2 5
3. BILL OF MATERIALS
Item Rev DescripƟon Qty Reference Designator MFG MFG P/N
1 DIODE RECT 200V 0.8A NPB MINIDIP 1 BR1 DIODES INC HD02-T
2 CAP 0.047uF ±5% 250V POLY NPb RAD 1 C1 EPCOS B32529C3473J
3 CAP 0.068uF ±10% 250V MPOLY NPb RAD 1 C2 PANASONIC ECQE2683KB
4 CAP 0.15uF ±10% 250V POLY NPb RAD 1 C3 EPCOS B32529C3154K
5 CAP 1uF ±10% 25V X7R NPb 0805 1 C4 TDK C2012X7R1E105K125AB
6 A CAP 0.047uF ±10% 25V X7R NPb 0603 1 C5 KEMET C0603C473K3RAC
7 A CAP 1000pF ±10% 50V X7R 0603 1 C6 KEMET C0603C102K5RAC
8 CAP 33uF ±20% 35V ALUM ELEC NPb RAD 1 C7 PANASONIC ECA1VHG330
9 CAP 680uF ±20% 35V AL ELEC NPb RAD 1 C8 PANASONIC EEUFR1V681
10 CAP 220pF ±10% 600V X7R NPb1206 0 C9 AVX 1206CC221KAT1A
11 CAP 56pF ±5% 50V C0G NPb 0603 0 C10 C11 KEMET C0603C560J5GAC
12 CAP 100pF ±10% 50V X7R CER NPb 0603 1 C12 TDK C1608X7R1H101K
13 CAP 2200pf ±10% 2KV X7R NPb 1210 1 CY JOHANSON DIELECTRICS 202S41W222KV4E
14 DIODE HS SWT 100V 150mA NPb SOD323 4 D1 D2 D4 D8 MICRO COMMERCIAL 1N4148WX-TP
15 DIODE 600V 1A NPb SMA DO-214AC 1 D3 D7 MCC GS1J-LTP
16 DIODE SKY RECT 150V 2A NPb DO-214AC 1 D6 MCC SS2150-LTP
17 DIODE ULT FAST 600V 1A NPb SMA 0 D9 ST MICROELECTRONICS STTH1L06A
18 RES 22 OHM 2W ±10% MTLFLM NPb AXIAL 1 F1 TT ELECTRONICS EMC2-22RKI
19 IND 10000uH 0.053A MINI-DRUM NPb TH 1 L1 RENCO RL-5480-3-10000
20 THERM 100K OHM ±5% 0.10mA NPb 0603 1 NTC MURATA NCP18WF104J03RB
21 TRAN MOSFET nCH 2.5A 600V NPb DPAK 1 Q1 ALPHA & OMEGA AOD3N60
22 TRAN MOSFET nCH 30V 5.8A NPb SOT23 1 Q2 DIODES INC DMN3404L-7
23 TRAN MSFET nCH 60V 360mA NPb SOT-23 1 Q3 NXP 2N7002P,215
24 RES 22 OHM 1/8W ±5% NPb 0805 FILM 1 R1 DALE CRCW080522R0JNEA
25 RES 750k OHM 1/8W ±1% NPb 0805 FILM 2 R2 R3 PANASONIC ERJ6ENF7503V
26 RES 4.7k OHM 1/8W ±5% NPb 0805 FILM 0 R4 DALE CRCW08054K70JNEA
27 RES 470 OHM 2W ±5% MTL FLM NPb AXL 1 R5 VISHAY PR02000204700JR500
28 RES 47 OHM 1/10W ±1% NPb 0603 2 R6 R13 PANASONIC ERJ3EKF47R0V
29 RES 10k OHM 1/4W ±1% NPb 1206 FILM 0 R7 R11 DALE CRCW120610K0FKEA
30 RES 80.6k OHM 1/10W ±1% 0603 FILM 1 R8 DALE CRCW060380K6FKEA
31 RES 39.2k OHM 1/10W ±1% NPb 0603 1 R9 DALE CRCW060339K2FKEA
32 RES 14k OHM 1/10W ±1% NPB 0603 FILM 1 R10 DALE CRCW060314K0FKEA
33 RES 1.8 OHM 1/4W ±1% NPb 1206 FILM 1 R12 DALE CRCW12061R80FKEA
34 RES 75k OHM 1/10W ±1% NPb 0603 FILM 1 R14 DALE CRCW060375K0FKEA
35 RES 2.61k OHM 1/10W ±1% NPb 0603 1 R15 DALE CRCW06032K61FKEA
36 RES 27K OHM 1/8W ±0.1% NPb 0805 1 R16 PANASONIC ERA-6YEB273V
37 RES 1k OHM 1/10W ±5% NPb 0603 FILM 1 R17 DALE CRCW06031K00JNEA
38 XFMR 0.9mH ±10% 10KHz NPb TH 1 TR1 KUNSHAN EAGERNESS EF16-CL011M
39 B1 IC CRUS TRIAC DIM PFC 120V NPb SO16 1 U1 CIRRUS LOGIC CS1615A-FSZ/B1
40 VARISTOR 240V 210pF 15J 7mm NPb RAD 1 VR1 BOURNS MOV-07D241K
41 DIODE ZENER 500mW 16V NPb SOD123F 1 Z1 NXP NZH16C,115
Figure 2. Bill of Materials
