WIKA operating instructions model 232.3x.063 with 851 per ATEX

11041781.03 03/2011 GB/D/F/E

3. Specifications ... 5. Transport, packaging and storage

Materials

Wetted parts:

Stainless steel

Movement:

Stainless steel

Dial and pointer:

Aluminium

Case, bayonet ring: Stainless steel (with blow-out back)

Window:

Laminated safety glass

For further specifications see WIKA data sheet PM 02.04 or PM 02.11 and

the order documentation.

4. Design and function

Description

■

Nominal size 63 mm

■

The instruments measure the pressure by means of resilient bourdon

tube pressure elements

■

The measuring characteristics are in accordance with the EN 837-1

standard

■

In addition, the enclosing and the pressurised components also meet

the requirements of this standard, relating to safety pressure gauges

with a solid baffle wall (code S3).

■

When the value exceeds or falls below the set limit, the built-in bistable

reed contact is switched.

Scope of delivery
Cross-check scope of delivery with delivery note.

5. Transport, packaging and storage

5.1 Transport

Check the pressure gauge for any damage that may have been caused by

transport. Obvious damage must be reported immediately.
