15 WIKA operating instructions pressure transmitter, model S-20
14043170.02 07/2014 GB/D/F/E
GB
4. Design and function
4.1 Description
The prevailing pressure is measured at the sensor element through the deformation of a diaphragm. By supplying
power, this deformation of the diaphragm is converted into an electrical signal. The output signal from the pressure
transmitter is amplified and standardised. The output signal is proportional to the measured pressure.
4.2 Scope of delivery
■ Pressure transmitter
■ Test report
■ Certificates (option)
■ Mating connector (option)
Cross-check scope of delivery with delivery note.
5. Transport, packaging and storage
5.1 Transport
Check the pressure transmitter for any damage that may have been caused during transportation.
Obvious damage must be reported immediately.
5.2 Packaging
Do not remove packaging until just before mounting.
Keep the packaging as it will provide optimum protection during transport (e.g. change in installation site, sending for
repair).
5.3 Storage
Permissible conditions at the place of storage:
■ Storage temperature: -40 ... +70 °C
■ Humidity: 67 % relative humidity (no condensation)
4. Design and function / 5. Transport, packaging and storage
