14 WIKA operating instructions pressure transmitter, model S-20
14043170.02 07/2014 GB/D/F/E
GB
Electrical connection Ingress
protection 2)
Wire cross-
section
Cable ∅ Cable
material
Permissible temperature
Circular connector M12 x 1 (4-pin, metallic)
without mating connector
IP 67 - - - -40 ... +125 °C (cULus: +85 °C)
(-40 ... +257 °F (cULus: +185 °F))
with mating connector, straight,
with moulded cable
IP 67 3 x 0.34 mm² 4.3 mm PUR -25 ... +80 °C
(-4 ... +176 °F)
with mating connector, straight,
with moulded cable, shielded
IP 67 3 x 0.34 mm² 4.3 mm PUR -25 ... +80 °C
(-4 ... +176 °F)
with mating connector, angled, with
moulded cable
IP 67 3 x 0.34 mm² 5.5 mm PUR -25 ... +80 °C
(-4 ... +176 °F)
Field case
IP 6K9K - - - -25 ... +100 °C
(-4 ... +212 °F)
Cable outlet
Cable outlet IP 67
IP 67 3 x 0.34 mm² 5.5 mm PUR -30 ... +100 °C
(-22 ... +212 °F)
Cable outlet ½ NPT conduit IP 67 6 x 0.35 mm² 6.1 mm PUR -30 ... +100 °C (cULus: +90 °C)
(-22 ... +212 °F (cULus: +194 °F))
Cable outlet IP 68 IP 68 6 x 0.35 mm² 6.1 mm PUR -30 ... +125 °C (cULus: +90 °C)
(-22 ... +257 °F (cULus: +194 °F))
Cable outlet IP 68, FEP IP 68 6 x 0.39 mm² 5.8 mm FEP -40 ... +125 °C (cULus: +105 °C)
(-40 ... +257 °F (cULus: +221 °F))
Cable outlet IP 6K9K IP 6K9K 6 x 0.35 mm² 6.1 mm PUR -30 ... +125 °C (cULus: +90 °C)
(-22 ... +257 °F (cULus: +194 °F))
Heavy-duty connector
with mating connector with cable
IP 68 6 x 0.14 mm² 6.5 mm PUR -40 ... +125 °C (cULus: -30 ... +90 °C)
(-40 ... +257 °F (cULus: -22 ... +194
°F))
2) Only applies when plugged in using a suitable mating connector that has the appropriate ingress protection
For special model numbers, e.g. S-20000, please note the specifications stated on the delivery note.
For further specifications see WIKA data sheet PE 81.61 and the order documentation.
