10 WIKA operating instructions pressure transmitter, model S-20
14043170.02 07/2014 GB/D/F/E
GB
3. Specifications
Specifications
Non-linearity (per IEC 61298-2) See test report
Relationship to the mounting position For measuring ranges < 1 bar (15 psi), an additional zero offset of up to 0.15 % applies
Non-repeatability ≤ ±0.1 % of span
Temperature hysteresis 0.1 % of span at > 80 °C (176 °F)
Long-term drift (per IEC 61298-2) ≤ ±0.1 % of span
≤ ±0.2 % of span (with special measuring ranges and measuring ranges < 1 bar (15 psi))
Temperature error For calibration temperature 15 ... 25 °C (59 ... 77°F)
-20 ... +80 °C: ≤1 % of span
-30 ... +100 °C: ≤1.5 % of span
For measuring ranges < 1 bar (15 psi), special measuring ranges and instruments with an
increased overpressure limit the respective temperature error increases by 0.5 % of span
Derating for cooling elements
■ Max. permissible ambient tempera-
ture
T
amb
(T
med
< 125 °C) = 125 °C
T
amb
(T
med
≥ 125 °C) = -0.62 x T
med
+ 202 °C
■ Max. permissible medium tempera-
ture
T
med
(T
amb
< 80 °C) = 200 °C
T
med
(T
amb
≥ 80 °C) = -1.61 x T
amb
+ 326 °C
T
amb
= Ambient temperature [°C]
T
med
= Medium temperature [°C]
Storage and transport conditions
■ Permissible temperature range -40 ... +70 °C (-40 ... +158 °F)
■ Maximum humidity (per IEC 68-2-78) 67 % r. h. at 40 °C (104 °F) (in accordance with 4K4H per EN 60721-3-4)
Climate class For indoor and outdoor use. Protect the instrument from direct sunlight.
■ Storage 1K3 (per EN 60721-3-1)
■ Transport 2K3 (per EN 60721-3-2)
■ Operation 4K4H (per EN 60721-3-4, without condensation or icing)
Vibration resistance (per IEC 68-2-6) 20 g, 10 ... 2,000 Hz (40 g, 10 ... 2,000 Hz for circular connector M12 x 1, metallic)
For instruments with cooling elements a limited vibration resistance of 10 g, 10 ... 2,000 Hz,
applies.
