WIKA operating instructions pressure transmitter, model R-1
14026284.01 11/2012 GB/D/F/E
GB
3. Specifications
3. Specifications
3.1 Measuring ranges
Relative pressure
bar Measuring range
0 ... 6
0 ... 10
0 ... 15
0 ... 16
0 ... 20
0 ... 25
0 ... 30
Overpressure limit
20
20
32
32
50
50
80
Burst pressure
100
100
160
160
250
250
400
Measuring range
0 ... 35
0 ... 40
0 ... 45
0 ... 50
0 ... 60
0 ... 100
0 ... 160
Overpressure limit
80
80
120
120
120
200
320
Burst pressure
400
400
550
550
550
800
1,000
psi Measuring range
0 ... 100
0 ... 150
0 ... 200
0 ... 250
0 ... 300
0 ... 350
0 ... 400
Overpressure limit
290
290
460
460
720
720
720
Burst pressure
1,450
1,450
2,300
2,300
3,600
3,600
3,600
Measuring range
0 ... 450
0 ... 500
0 ... 550
0 ... 600
0 ... 650
0 ... 700
0 ... 750
Overpressure limit
1,100
1,100
1,100
1,100
1,100
1,700
1,700
Burst pressure
5,800
5,800
5,800
5,800
5,800
7,900
7,900
Measuring range
0 ... 800
0 ... 850
0 ... 1,500 0 ... 2,400
Overpressure limit
1,700
1,700
2,900
4,600
Burst pressure
7,900
7,900
11,600
14,500
