WIKA operating instructions pressure transmitter, model R-1
14026284.01 11/2012 GB/D/F/E
GB
3. Specifications
Vacuum and +/- measuring range
bar Measuring range
-1 ... +7
-1 ... +9
-1 ... +10
-1 ... +15
Overpressure limit
20
20
20
32
Burst pressure
100
100
100
160
Measuring range
-1 ... +20
-1 ... +25
-1 ... +29
-1 ... +45
Overpressure limit
50
50
80
120
Burst pressure
250
250
400
550
Measuring range
-0.5 ... +7
-0.5 ... +10
Overpressure limit
20
20
Burst pressure
100
100
psi
Measuring range
-30 inHg ... +100
-30 inHg ... +145
-30 inHg ... +200
-30 inHg ... +250
Overpressure limit
290
290
460
460
Burst pressure
1,450
1,450
2,300
2,300
Measuring range
-30 inHg ... +300
-30 inHg ... +350
-30 inHg ... +400
-30 inHg ... +450
Overpressure limit
720
720
1,100
1,100
Burst pressure
3,600
3,600
5,800
5,800
Measuring range
-30 inHg ... +500
-30 inHg ... +550
-30 inHg ... +600
Overpressure limit
1,100
1,100
1,700
Burst pressure
5,800
5,800
7,900
Other measuring ranges on request
Vacuum tightness
Yes
