3. Specifications / 4. Design and function
Specifications
Permissible temperature ranges
■
Medium
-40 ... +125 °C
■
Ambient
-40 ... +100 °C, for cable outlet a limited temperature range of -40 ... +90 °C applies
■
Storage
-40 ... +120 °C, for cable outlet a limited temperature range of -40 ... +90 °C applies
Rated temperature range
0 ... +80 °C
CE conformity
■
Pressure equipment directive
97/23/EC
■
EMC directive
2004/108/EC, EN 61326 emission (group 1, class B) and interference immunity (industrial application)
Weight
approx. 70 g
For special model numbers, e.g. OT-10000, please note the specifications stated on the delivery note.
For further specifications see WIKA data sheet PE 81.42 and the order documentation.
4. Design and function
4.1 Description
The prevailing pressure is measured at the sensor element through the deformation of a diaphragm. By supplying
power, this deformation of the diaphragm is converted into an electrical signal. The output signal from the pressure
transmitter is amplified and standardised.
4.2 Scope of delivery
Cross-check scope of delivery with delivery note.
