4. Design and function
4.1 Description
Design
CE conformity:
2004/108/EG Electromagnetic compatibility (EMC)
2002/95/EC RoHS (restriction of the use of certain hazardous
substances in electrical and electronic equipment)
Accuracy
±1.5 %
(with measuring range -250 ... +250 Pa: ±3 %)
Measuring ranges
■ Variant 1: 0 ... 2,500 Pa standard
(-100 ... +100/0 ... 100/250/500/1,000/1,500/2,000 Pa adjustable via
jumper)
■ Variant 2: 0 ... 7,000 Pa standard
(0 ... 1,000/1,500/2,000/2,500/3,000/4,000/5,000 Pa adjustable via
jumper)
■ Variant 3: -250 ... +250 Pa (-25 ... +25/-50 ... +50/
-100... +100/0 ... 25/50/100/250 Pa adjustable via jumper)
Pressure limitation
Maximum pressure: 25 kPa
Burst pressure: 50 kPa
Permissible temperature
Ambient: -20 … +70 °C
Operation: -5 … +50 °C
Permissible ambient humidity
0 … 95 % rH, non-condensing
4.2 Scope of delivery
Cross-check scope of delivery with the delivery note.
