Parts List( DB93-09771D)
NO Parts Code Parts Description Spec. QT'Y SA/SNA
1 DB93-13119A
ASSY CONNECTOR WIRE-
COMM(MAIN TO INV)
MAN U 1 SNA
2 DB59-00016A AC REACTOR-1PHASE 30A RC100PHXEA 1 SNA
3 DB62-10902A HEAT SINK-1PHASE 30A
FJM,AL,10mm,187mm,200mm,COUNT-
SINK,45mm
1 SNA
4 DB93-09902C ASSY CONTROL OUT HP,INV,CAC,LCI 4/5# CASE_PBA 1 SA
4-1 DB93-11110A ASSY PCB SUB-EMI ASSY, RC100SHXEC 1 SA
4-2 DB93-12326C ASSY MAIN PCB ASSY, RC100SHXEC 1 SA
5 DB93-11112D ASSY PCB MAIN-INVERTER ASSY, RC140SHXEC 1 SNA
6 DB61-05286A CASE-INV LCI ,OUTDOOR,ABS,VE-0860SE,SSEC,LCI 1 SNA
7 DB93-09793A ASSY CONTROL OUT HP,inv,CAC,LCI 4/5#,T_B PLATE 1 SA
8 6002-000536A SCREW-TAPPING TH,+,NO,2S,M4,L18,ZPC(WHT),SWRCH18A 2 SNA
9 6002-000231 SCREW-TAPPING TH,+,NO,2S,M4,L12,ZPC(WHT),SWRCH18A 4 SNA
10 DB91-00306A ASSY-SCREW MACHINE
BLDC INV.
CONTROLLER,M3*16,WSP,PH,+,ZPC
2 SNA
11 DB91-00307A ASSY-SCREW MACHINE WW-INV,M4*16,WSP,PH,+,ZPC 2 SNA
12 6001-001054 SCREW-MACHINE TH,+,NO,M4,L10,ZPC(WHT),SM20C,- 4 SNA
13 0205-001303 OIL-SILICON SF9038A,OIL-SILICON,g 7 SNA
14 6009-001001 SCREW-SPECIAL TH,+,WT,M4,L10,ZPC(WHT),SWRCH18A 1 SNA
15 6002-000216 SCREW-TAPPING TH,+,NO,1,M4,L20,ZPC(WHT),SWRCH18A 4 SNA
16 6003-001150 SCREW-TAPTYPE PH,+,WP,S,M5,L12,ZPC(BLK),SWRCH18A 2 SNA
17 DB93-12214A
ASSY CONNECTOR WIRE-
POWER
LCI 4#,POWER,UL1007 AWG22,SKY-
BLUE,BRN,130mm
0 SNA
18 6001-001054 SCREW-MACHINE TH,+,NO,M4,L10,ZPC(WHT),SM20C,- 2 SNA
