4- 2 Samsung El ect r onic s
4-1 Indoor Unit
No Par t s Pr ocedur e Remark
1 PANEL-FRONT 1) Stop the driving of air conditioner and
shut
off
main power supply.
2) Open the FRONT-GRILLE and pull out from
the PANEL-FRONT.
3) Detach COVER-TERMINALfrom the PANEL-
FRONT.(use + Screw Driver )
4) Loosen connect or wire(white) and detach the
temperature sensor wire .
5) To detach the FRONT-PANELthe main frame,
unfasten 2 screw at the bottom.(use + Screw
Driver )
6) Take off the FRONT-PANEL,lifting up the bottom.
