Page 10: Table 5: technical specifications
Technical Specifications
7
6 Technical
Specifications
Table 5 defines the technical specifications
1
:
Table 5: Technical Specifications
2
of the TP-100 / TP-200
INPUTS:
TP-100: 1 XGA input on an HD15F connector; 1 XGA Loop on an HD15F connector
TP-200: 1 UTP CAT5 connector (Line IN)
OUTPUTS:
TP-100: 2 UTP CAT5 connectors (Line 1 OUT; Line 2 OUT)
TP-200: 1 UTP CAT5 connector (Line OUT); 3 XGA outputs on HD15F connectors
MAX. OUTPUT LEVEL: 1.5 Vpp / 75
Ω
DIFF. GAIN (Pair):
0.23% (optimum)
DIFF. PHASE (Pair):
0.19 Deg (optimum)
K-FACTOR (Pair):
<0.05% (optimum)
S/N RATIO (Pair):
70dB (optimum)
RESOLUTION:
Up to UXGA
RANGE:
Up to 150m with CAT5 UTP
CONTROLS: (30m):
TP-100: Line Out E.Q.: 0 to 7.8dB @ 20MHz
TP-200: XGA Out E.Q.: 0 to 3.2dB @ 20MHz
COUPLING: DC
POWER SOURCE:
TP-100 / TP-200: 230 VAC, 50/60 Hz. (115VAC, U.S.A.) 13 VA
DIMENSIONS:
22cm x 18cm x 4.5cm (8.6” x 7” x 1.8”), W, D, H.
WEIGHT:
1.2 kg. (2.65 lbs.) approx.
ACCESSORIES: Power
cords
OPTIONS:
19” rack adapters RK-80 (holds two units)
1 Specifications for 30m of CAT5 UTP cable, unless otherwise specified
2 Specifications are subject to change without notice
