Technical Specifications
11
6 Technical Specifications
Table 5 defines the technical specifications
1
:
Table 5: Technical Specifications
2
of the TP-9/TP-10
TP-9 TP-10
INPUTS: 1 composite video 1Vpp/75
Ω on a
BNC connector
1 s-Video 1Vpp/75
Ω [Y], 0.3Vpp/75Ω
[C] on a 4-pin connector
1 S/PDIF (digital audio) on an RCA
connector
1 audio (analog audio) <0dBu on a
3.5mm mini connector
1 RJ-45 CAT-5 shielded connector (LINE IN)
OUTPUTS: 1 RJ-45 CAT-5 shielded connector
(LINE OUT)
2 IR emitters on 3.5mm mini
connectors 1 composite video 1Vpp/75
Ω on a BNC
connector
1 s-Video 1Vpp/75
Ω [Y], 0.3Vpp/75Ω [C] on a
4-pin connector
1 S/PDIF (digital audio) on an RCA connector
1 audio (analog audio) <8dBu on a 3.5mm
mini connector
VIDEO Specifications
MAX. OUTPUT LEVEL: 2.6V
BANDWIDTH:
≥70MHz/-3dB
NON-LINEARITY: <0.05%
DIFF. GAIN: <0.05%
DIFF. PHASE: 0.09Deg
S/N RATIO: >75dB RMS/5MHz weighted
AUDIO Specifications
MAX. OUTPUT LEVEL: 0dBu
BANDWIDTH: 20Hz to 20kHz/0.1dB
CONVERSION SAMPLE RATE: 48kHz
CONVERSION RESOLUTION: 24 bits
S/N RATIO: >73dB
POWER SOURCE: 12V DC, 95mA 12V DC, 82mA
DIMENSIONS: 12cm x 6.95cm x 2.76cm (4.7" x 2.8" x 1.08") W, D, H
WEIGHT: 0.3 kg (0.67 lbs.) approx
ACCESSORIES: Power Supply, 3.5mm to IR Emitter Control Cable (C-A35/IRE-10)
OPTIONS: 15m (50ft) cable and 20m (65ft) IR Emitter Extension Cables
1 Specifications for 100m of CAT 5 UTP cable, unless otherwise specified
2 Specifications are subject to change without notice
