711N, 712N - Technical Specifications
6
Technical Specifications
711N
712N
INPUT:
1 composite video
1Vpp/75Ω, on a BNC
connector; 1 stereo
unbalanced audio
4dBm/50kΩ, on two RCA
connectors
1 RJ-45 CAT-5 shielded connector
(LINE IN)
OUTPUT:
1 RJ-45 CAT-5 shielded
connector (LINE OUT)
1 composite video 1Vpp/75Ω, on a
BNC connector; 1 stereo
unbalanced audio 4dBm/50kΩ, on
two RCA connectors
VIDEO MAX. SIGNAL LEVEL:
2.8Vpp
AUDIO MAX. SIGNAL LEVEL:
7.6Vpp
VIDEO BANDWIDTH (-3dB):
85MHz
AUDIO BANDWIDTH (-3dB):
>100kHz
DIFF. GAIN:
0.04%
DIFF. PHASE:
0.25Deg.
K-FACTOR:
0.1%
VIDEO S/N RATIO:
75dB
AUDIO S/N RATIO:
77dB
AUDIO CROSSTALK (all hostile)
-53dB @ 5MHz, video into audio
CONTROLS
LEVEL: -1.3dB to +6.3dB
EQ @ 30MHz: 0dB to +3.7dB
VIDEO COUPLING:
DC
AUDIO COUPLING:
Input: AC; line output: DC
DC for both line input and output
AUDIO THD + NOISE:
0.026%, 1kHz
AUDIO 2nd HARMONIC:
0.001% @ 1kHz
POWER SOURCE:
12V DC 50mA, when 712N
is fed by an independent
12V supply; 135mA when
feeding 712N
12V DC 45mA, when 711N is fed
by an independent 12V supply
OPERATING TEMPERATURE:
0° to +55°C (32° to 131°F)
STORAGE TEMPERATURE:
-45° to +72°C (-49° to 162°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12cm x 7.15cm x 2.76cm (4.7" x 2.8" x 1.08"), W, D, H
WEIGHT:
0.3 kg. (0.67 lbs.) approx. (each)
ACCESSORIES:
Power supply, mounting bracket (each)
OPTIONS:
RK-T1, RK-T3, 19 inch rack adapters
Specifications are subject to change without notice
For the most updated resolution list, go to our Web sit
