4 673T, 673R - Overview
3 Overview
The 673T is a high-performance fiber optic transmitter for 3G HD-SDI, HD-SDI,
SDI, and dual-link SDI signals. The unit converts up to four channels of serial
digital signals on gold-plated BNC connectors to light pulses that are transmitted
over a single multimode fiber optic cable to a 673R receiver that converts them
back to serial digital signals. The 673T and 673R pair has a transmission range of
1000 meters (more than 3,200ft).
Both the 673T and 673R:

Feature a maximum data rate of up to 3Gbps, enabling it to be used for
standard definition, high definition and the new 3G high definition serial
digital video signals (SD/HD-SDI)

Feature a single multimode OM3 fiber optic with SC connectors

Include four HD-SDI signals on gold-plated BNC connectors each for the
transmitter and the receiver

Support SDI, HD-SDI, 3G HD-SDI and dual-link and support data rates of
270Mbps, 1483.5Mbps, 1485Mbps and 2970Mbps

Are strictly regulated in accordance with Class 3R Laser Eye Safety in
compliance with ANSI Z136 and IEC 60825-1:2007

Feature HDTV compatibility

Include cable equalization up to 350m for SD signals, 140m for 1.5GHz HD
signals, and 120m for 3GHz HD signals
Standard Definition (SD) means an NTSC or PAL compatible video format, consisting of
480 (for NTSC) or 576 (for PAL) lines of interlaced video. High Definition (HD) means a
video format, consisting of 720 active lines of progressive video or 1080 lines of
progressive or interlaced video

Feature fiber optic, output and input indication LEDs

Include reclocking and equalization on each channel

Include 5V DC power adapters and housing in Kramer DigiTOOLS
®
enclosures

Can be rack mounted in a 1U rack space with the optional RK-3T rack
adapter
