8 650T/650R - Connecting the 650T/650R
5 Connecting the 650T/650R
You can use the 650T DVI-Coax Transmitter and the 650R Coax-DVI Receiver to
configure an DVI-to-Coax Transmitter and Receiver system (see Figure 3 ).
Always switch off the power to each device before connecting it to your
650T/650R. After connecting your 650T/650R, connect its power and
then switch on the power to each device.
To connect the DVI-to-Coax Transmitter and Receiver system as shown in the
example in Figure 3 , do the following:
1. Connect an DVI source, for example, the DVI output from a Blu-ray DVD
player, to the 650T DVI IN connector.
2. Connect the 650R DVI OUT connector to the DVI acceptor, for example, a
projector.
3. If using a 4-plug coax cable or 4 coax cables:
 Connect the 650T red, green, blue, and clock BNC connectors to the
650R red, green, blue and, clock BNC connectors
 Connect 12V DC power supplies to both the 650T and the 650R (not
shown in Figure 3 ). The remote power and IR remote control functions
are not available
4. If using a 5-plug coax cable or 5 coax cables:
 Connect the 650T red, green, blue, clock, and power BNC connectors
to the 650R red, green, blue, clock, and power BNC connectors
 Connect one 12V DC power supply to either the 650T or the 650R (not
shown in Figure 3 ). Power and the IR remote control function are
transmitted over the power coax connection to the second device
Note: All coax cables must be the same length. There can be no more than 6
inches (15cm) difference in length between any of the cables.
5. Connect the power supply(s) to the mains electricity.
After all connections are made and the units are powered ON, the system
operates.
