614T, 614R - Technical Specifications

Technical Specifications

INPUTS:

1 single link DVI-D (614T), 1 multimode fiber optic with
SC connector (614R)

OUTPUTS:

1 multimode fiber optic with SC connector (614T), 1
single link DVI-D (614R)

MAX DATA RATE:

2.25Gbps, up to WUXGA, 2K or 1080p @36bit color
depth (does not support XGA)

MAX. RANGE:

500m (1640ft) over 50/125



m multi-mode fiber at

WUXGA (1920x1200), 60Hz refresh rate

POWER CONSUMPTION:

5V DC, 300mA max. (614T); 200mA max. (614R)

OPERATING TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY:

10% to 85%, RHL non-condensing

DIMENSIONS:

3.9cm x 5.6cm x 1.46cm (1.5" x 2.2" x 0.57") W, D, H

WEIGHT:

0.14kg (0.31lbs) approx.

INCLUDED ACCESSORIES:

Two 5V DC/1A power supplies

Specifications are subject to change without notice at
