Technical Specifications
16
8
Technical Specifications
includes the technical specifications:
Table 5: Technical Specifications
INPUTS:
of the SP-11D Digital Video Processor
1 composite video: 1Vpp/75Ω on a BNC connector; 1 Y/C: 1Vpp/75Ω (Y),
0.3Vpp/75Ω (C) on a 4‑pin connector; 1 component: Y/R‑Y/B‑Y (or
RGB/S) 1Vpp/0.7Vpp/0.7Vpp/75Ω on BNC connectors; 1 SYNC (genlock):
looped 75Ω/Hi‑Z on BNC connectors; 1 SDI: SMPTE-259M, ITU-R BT.601
on a BNC connector
OUTPUTS:
1 composite video: 1Vpp/75Ω on a BNC connector; 1 Y/C: 1Vpp/75Ω (Y),
0.3Vpp/75Ω (C) on a 4-pin connector; 1 component: Y/R-Y/B-Y (or RGB/S)
1Vpp/0.7Vpp/0.7Vpp/75Ω on BNC connectors; 2 SDI: SMPTE-259M, ITU-
R BT.601 on BNC connectors
SDI INPUT/OUTPUT:
SMPTE‑259M, ITUR BT.601 on BNC connectors
VIDEO STANDARDS:
PAL-B/D/G/H/I/M/N, NTSC-3.58/4.43, SECAM
DIGITAL RESOLUTION:
10 bits
BANDWIDTH:
5.5MHz (‑0.5dB)
DIFF. GAIN:
1%
DIFF. PHASE:
1Deg
K-FACTOR:
0.4%
S/N RATIO:
60dB
LUMA NON-LINEARITY:
1%
CHROMA / LUMA DELAY: <15ns
MEMORY:
Non-volatile memory for storage of 16 setups
CONTROLS:
Front-panel and RS-232: Contrast, brightness, video gain, color, hue, H/V
sharpness, SCH phase, delay, H/V shift; R, G, B, R-Y, B-Y level; screen
splitter (process to bypass); freeze; panel lock
INDICATORS:
Multi-character display on the front panel
POWER SOURCE:
Universal, 100-240VAC, 50/60Hz
DIMENSIONS:
19” x 7” x 1U W, D, H, rack mountable
WEIGHT:
2.6 kg. (5.7 lbs.) approx.
ACCESSORIES:
Power cord, null-modem adapter
1 Specifications are subject to change without notice
