Using Your FC-7402 SDI to Analog Converter
8
5.2 Operating the FC-7402 SDI to Analog Converter
Operate your FC-7402 via:
• The front panel buttons
• RS-232 serial commands transmitted by a touch screen system, PC, or
other serial controller
To operate the FC-7402 using the front panel buttons, do the following:
1. Turn on the power.
The signal from the SDI source is automatically converted to composite video,
s-Video, and component video (YUV if DIP 1 is set to OFF, or RGB if DIP 1
is set to ON).
2. If necessary, adjust the brightness, contrast, hue, sharpness, and/or color
of the picture, as follows:
• Press the appropriate button 1
The button illuminates and the 7-segment display shows the current level (in digits)
• Press and release the + button or - button once to gradually increase or
decrease the current level by one unit
The 7-segment display shows the new level
Note: To increase or decrease the current level rapidly, press and hold down
the + button or - button, continuously
2
. To end the rapid adjustment, release
the + button or – button.
5.2.1 Storing/Recalling Setups
You can store and recall up to 10 setups (or adjustments) in non-volatile
memory, using the STO and RCL buttons together with the + and – buttons.
To store
3
a setup, do the following:
• Press the STO button and then select a setup # between 1 and 10 by
pressing the + and – buttons
• Press the STO button again
The current settings are saved to that setup #
To recall a setup, do the following:
• Press the RCL button and then select the appropriate # (that corresponds
to the setup #) by pressing the + and – buttons
• Press the RCL button again
The selected setup is recalled
1 See items 2 to 6 in Table 1
2 The 7-segment display starts to quickly scan the range. When it stops running, it has reached the maximum or minimum,
respectively
3 Storing a new setup over a previous setup # replaces the previous setup #
