Technical Specifications
12
7 Technical Specifications
Table 4 includes the technical specifications of the 6808 SDI-AES
De-Embedder and the 6809 SDI-AES Embedder:
Table 4: Technical specifications
1
of the 6808 / 6809
6808 6809
INPUTS: 1 x SDI @ 270Mbits/s 1 x SDI, 2 x AES/EBU on BNC Connectors
OUTPUTS: 1 x SDI, 2 x AES/EBU 1 x SDI on a BNC Connector
CONTROLS: Group Select Group Select
POWER SOURCE: 12 VDC, 300mA 12 VDC, 400mA
DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7" x 0.98" x 2.95"), W, D, H
WEIGHT: 0.3kg. (0.66lbs.)
ACCESSORIES: Power supply, mounting bracket
OPTIONS: 19” rack adapters RK-T1, RK-T3
1 Specifications are subject to change without notice
