Using the SDI-AES De-Embedder / SDI-AES Embedder
7
5.2.1 Setting the GROUP SELECT Dipswitches
Set the GROUP SELECT dipswitches 1 to choose the audio group. For
example, to choose audio group 3, set DIP 3 OFF 2 .
Table 3: GROUP SELECT Dipswitch Settings
DIP Description
1 Selects audio group 1
2 Selects audio group 2
3 Selects audio group 3
4 Selects audio group 4
On the 6809, you can delete the entire vertical blanking interval (VBI) data
and embed the audio to Group 1, by setting all four GROUP SELECT
dipswitches ON. This lets you input an SDI stream with other (undesired)
embedded audio or other VBI information. The 6809 will delete this data and
start a new audio chain (cascading up to four 6809 units).
1 Item 7 in Figure 1 (the 6808 SDI-AES De-Embedder) and in Figure 2 (the 6809 SDI-AES Embedder)
2 The highest number DIP takes priority. For example, if DIP 2 and DIP 3 are both OFF, audio group 3 is chosen; if all DIPs
are OFF, audio group 4 is chosen
